Frame
Zendit Stealth Air full Carbon, Updated Zero Suspension System, 165mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.
Sizes
S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm
-
Rear shock
Fox Float X2 Factory Kashima 205x65mm. 2-positions lever compresion (Open/Firm), low-speed compression, low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings.
Shock settings
CS 30 compression, 1,1 Bleed, RS40 rebound, Rezi B40, LML, Long MCU, 0 volume spacers.
-
Fork
Fox Podium 29 Float GRIP X2 Factory Kashima, 170mm, tapered steerer tube, Boost 20x110mm thru axle, 44mm offset. High and low-speed compression, high and low-speed rebound, air preload.
Fork remote
N/A
-
Headset
Acros custom ZS56/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs, with blocklock: S, M / without blocklock: ML, L, XL.
Stem
Onoff S9 30mm 0º, Full CNC, 31.8mm barbore.
-
Handlebar
Onoff S9 1.0 Carbon, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise.
Grips
Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size.
-
Seatpost
RockShox Reverb AXS, diameter 31.6mm, w/AXS Pod Controller Rocker Paddle. S size: 398.2x125mm, M size: 448.2x150mm,ML size: 498.2x175mm, L size: 548.2x200mm, XL size:548.2x200mm.
Saddle
Ergon SM10 E-Mountain Black.
-
Front brake
Sram Maven Ultimate, 18 millimeter 4-piston caliper, HS2 220mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
Rear brake
Sram Maven Ultimate, 18 millimeter 4-piston caliper, HS2 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
-
Brake lever
Sram Maven Ultimate , Carbon lever, SwingLink and lever pivot bearings, tools-free reach adjust
Rims
DT Swiss, Carbon
-
Spokes
DT Hybrid II Straightpull, w/DT ProLock Squorx ProHead aluminum nipples, Three-cross (1:1) pattern.
Front hub
DT Swiss 350, 20x110mm Boost, Disc IS (6-bolt).
-
Rear hub
DT Swiss 350, 12x148mm Boost, Disc IS (6-bolt), Sram XD Steel (SRAM) freehub body, 72T Ratchet DEG DF System.
Front tire
Maxxis Assegai 29x2.5WT, tubeless ready, 3C Maxx Grip compound, DD protection, 120x2TPI, folding bead
-
Rear tire
Maxxis Minion DHR II 27.5x2.5 WT, tubeless ready, 3C MaxxTerra compound, DD protection, 120x2TPI, folding bead
Crankset
e*thirteen Helix Race Carbon e*spec. All sizes: 155mm
-
Rings
Sram XX Eagle 36T T-Type, 104BCD, steel, CL55
Bottom bracket
N/A
-
Pedals
N/A
Chain
Sram GX Eagle T-Type, 12s, w/Powerlock
-
Front derrailleur
N/A
Rear derrailleur
Sram X0 Eagle AXS T-Type, 12s
-
Shift levers
Sram Eagle AXS Pod Controller Rocker Paddle w/discrete clamp, 12s
Casette
Sram XS 1275, 10-52T, T-Type, 12s
-
Derailleur hanger
Not included - UDH compatible
Weight
23.1 Kg
-
Display
Avinox DP100 Display / Avinox BC100 Wireless Controller (L&R)
Motor
Avinox Drive Unit
